IEC 309 HP: range of plugs and socket-outlets compliant with international Standards IEC 60309-1 and IEC
60309-2, assimilated at European level as EN 60309-1 and EN 60309-2. This range expands the GEWISS
assortment of mobile plugs, mobile and recessed sockets for currents from 16 to 125A with IP44 / IP54
protection ratings and ratings up to IP66 / IP67 / IP68 / IP69 to ensure total protection in all possible
applications. The technopolymers and thickness used for the parts made of insulating material guarantee an
elevated degree of mechanical and chemical agent resistance. All the sleeves and pins of the IEC 309 HP
socket-outlets and plugs are surface-treated with nickel-plating to ensure full protection against corrosion,
oxidation and abrasion. All the external metallic elements of the IEC 309 HP plugs and socket-outlets are
made of stainless steel (the threaded metallic inserts for the body-grip coupling of the 63-125A versions are
made of brass).
Colour Red Rated current (A) 125
IP degree IP66/IP67/IP68/IP69 No. of poles 3P+N+E
Mechanical resistance IK09 Reference h 6
Type Straight connector Rated voltage 346 - 415 V
Frequency 50/60 Hz Terminal tightening capacity 16-50mm² flexible cables - 25-70mm² rigid cables
Cable clamp tightening capacity 29,9-49 mm Operating temperature -25 +55 °C
Type of wiring Mantle terminal Type of material Halogen-free in compliance with EN 60754-2
Electrocod 2211 Glow wire test 850 °C (active parts) - 650 °C (passive parts)
Total number of operations > 500 Breaking capacity at 1.1 Un 156 A
Insulation resistance > 10 MΩ Thermo-pressure with ball 125 °C (active parts) - 80 °C (passive parts)

Connector GW-62-061 Gewiss GW62061

SKU 15A
IEC 309 HP: range of plugs and socket-outlets compliant with international Standards IEC 60309-1 and IEC
60309-2, assimilated at European level as EN 60309-1 and EN 60309-2. This range expands the GEWISS
assortment of mobile plugs, mobile and recessed sockets for currents from 16 to 125A with IP44 / IP54
protection ratings and ratings up to IP66 / IP67 / IP68 / IP69 to ensure total protection in all possible
applications. The technopolymers and thickness used for the parts made of insulating material guarantee an
elevated degree of mechanical and chemical agent resistance. All the sleeves and pins of the IEC 309 HP
socket-outlets and plugs are surface-treated with nickel-plating to ensure full protection against corrosion,
oxidation and abrasion. All the external metallic elements of the IEC 309 HP plugs and socket-outlets are
made of stainless steel (the threaded metallic inserts for the body-grip coupling of the 63-125A versions are
made of brass).
Colour Red Rated current (A) 125
IP degree IP66/IP67/IP68/IP69 No. of poles 3P+N+E
Mechanical resistance IK09 Reference h 6
Type Straight connector Rated voltage 346 - 415 V
Frequency 50/60 Hz Terminal tightening capacity 16-50mm² flexible cables - 25-70mm² rigid cables
Cable clamp tightening capacity 29,9-49 mm Operating temperature -25 +55 °C
Type of wiring Mantle terminal Type of material Halogen-free in compliance with EN 60754-2
Electrocod 2211 Glow wire test 850 °C (active parts) - 650 °C (passive parts)
Total number of operations > 500 Breaking capacity at 1.1 Un 156 A
Insulation resistance > 10 MΩ Thermo-pressure with ball 125 °C (active parts) - 80 °C (passive parts)
$99.00
